V5

The Studiomaster V5 line array is a new development of a two way system providing superior performance with a flat frequency response and phase response in a range of 60Hz-20KHz. Ultra compact yet provides impressive power levels.

The V5 HF/MF system consists of a two 5” MF drivers combined with a 44mm HF compression driver. This tuned combination greatly reduces the cabinets weight and size, yet still produces high volume and SPL specifications.

The trapezoidal enclosure is designed to keeps the loudspeakers operating the way they are intended with sound dispersion aimed towards the front.

The aluminium suspension system provides 0°- 10° of adjustment to achieve the ideal positioning. Connections to the V5 are through two NL4MP 4pin connectors. The cabinets are finished in a special elastic effect hard wearing paint, and are further protected with a tough grille.

The matching V5S LF passive cabinet uses the same small footprint cabinet shape as the smaller V5 HF/MF unit. The V5S features two 10“ high power LF drivers with 2.6” voice coils. The vented horn design further improves the already high efficiency.

If you choose the active sub bass the V5SA to drive your system, then you will benefit from all the features of the V5S, but also have your sound amplified through the built in linear amplifier with DSP audio processing, to perfectly match your signal to the cabinets.

The power amp module boasts variable speed fan cooling, overload and short circuit protection. Thermal protection is intelligent and linked to the DSP. If temperatures rise out of the set limit, the DSP will attenuate the output from the amplifier, and if required for protection shut down the amplifier to ensure future reliability.

Status LEDs to show overload and peak situations are easily visible fom the rear panel.
